Thermal Insulation Colored Cable Sleeves Clean Cut Halogen Free RoHS Certification

Thermal Insulation Colored Cable Sleeves Clean Cut Halogen Free RoHS Certification

    • Thermal Insulation Colored Cable Sleeves Clean Cut Halogen Free RoHS Certification
    • Thermal Insulation Colored Cable Sleeves Clean Cut Halogen Free RoHS Certification
  • Thermal Insulation Colored Cable Sleeves Clean Cut Halogen Free RoHS Certification

    Product Details:

    Place of Origin: Shenzhen of China
    Brand Name: Huiyunhai
    Certification: UL, RoHS, REACH, SGS, ISO
    Model Number: HYH- C

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 meters
    Packaging Details: standard export carton
    Payment Terms: T/T, Western Union
    Supply Ability: 3 million meters per month
    Contact Now
    Detailed Product Description
    Material: PET Size: Custom
    Color: Colorful Flammability: VW- 1
    Melt Point: 250°C±5°C Sample: Free

    Non Fray Thermal Insulation Clean Cut Braided Sleeving For Cable Protection


    Features & Benefits is obvious:

    Low cost
    Prevent tangled rods
    Easy push on -push off installation
    impervious to mold or mildew
    Breathable& will not retain water
    lightweight, expandable and flexible
    High abrasion resistance
    UV resistance
    Available for casting and spinning rod

    Application:
    Outdoor field if the hot knife is not available, for example when installing telecom equipment installation in mountain areas.


    Expandable clean cut sleeving is braided by environment-friendly polyester monofil. (PET,PA6,PA66,PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.

    Description for braided sleeves

    Clean cut sleeving can be cut with a common scissors without obvious fray. It has some more advantages than standard polyester sleeving , softer and easier to be used on the outdoor field where the power or a hot knife could not be available. It also provides the same excellent protection of anti-abrasion as standard polyester sleeving.


    Part 1--Advantage:

    1. Can be cut by scissor and not fray
    2.. Light Weight & Flexible
    3. Abrasion Resistant
    4. Flame retardant
    5. perfect for field


    Part 2--Introduce

    1.  Flame-retardant and halogen-free.
    2. Can be cut with a common scissors without obvisous fray.
    3. Softer and easier to be use on the outdoor field .
    4.  It offers durable abrasion resistance in a wide range of industrial applications.
    5.  The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    6.  Totally expanded the sleeving can reach at least one point five times than the initial dimension.


    Detailed Description


    Model Number: Clean Cut Expandable Sleeving
    Material: Polyester (PET) & Polyamide ( PA ) & Polypropylene (PP)
    Working Temperature: -50~150C
    Melting point: 250°C±5
    Flame resistant grade: UL VW-1
    Usage: Expandable sleeving is widely used in bounding and protecting of electrical cables, automobile and aviation sectors.
    Color: Black, Grey, Red, Yelllow, Green, White, Clear, Blue, Purple, Pink etc
    Yarn Number: One, two, three, four


    Dimensions:


    Nominal size (W) Part No. Expandable Rang Packing (L)
    Inch mm Min.(I) mm Max.(O)mm Standard spool(m)
    1/8" 3 CC-003 1 5 500
    1/4" 6 CC-006 3 8 500
    5/16" 8 CC-008 5 10 350
    3/8" 10 CC-010 7 12 350
    1/2" 12 CC-012 8 14 300
    5/8" 16 CC-016 10 18 250
    3/4" 19 CC-019 14 23 200
    1" 25 CC-025 18 28 200
