Security Cable PET Expandable Braided Sleeving For 2mm Wire Protection Cover

Security Cable PET Expandable Braided Sleeving For 2mm Wire Protection Cover

    • Security Cable PET Expandable Braided Sleeving For 2mm Wire Protection Cover
    • Security Cable PET Expandable Braided Sleeving For 2mm Wire Protection Cover
  • Security Cable PET Expandable Braided Sleeving For 2mm Wire Protection Cover

    Product Details:

    Place of Origin: Shenzhen of China
    Brand Name: Huiyunhai
    Certification: UL, RoHS, REACH
    Model Number: HYH

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 meters
    Packaging Details: Standard export carton
    Contact Now
    Detailed Product Description
    Name: Pet Expandable Braided Sleeve Material: Pet
    Temperature: -50 ℃~+125 ℃ Feature: Expandable
    Tinting Strength: 100±5℃ Lead Time: 5 Days

    Security Cable Pet Expandable Braided Sleeving For 2mm Wire Protection Cover



    1. Description of pet expandable braided sleeve



    Pet expandable braided sleeve compiled by the Environmental Protection PET filament diameter monofilament 0.20mm or 0.25mm's made with good flexibility, flame resistance, abrasion resistance and heat resistance, network management can be easily expanded to the original 150% , and it is easy to tighten the various irregularly shaped objects, which can be maintained within a wide temperature range while maintaining a soft, can inhibit chemical corrosion, UV and friction, characterized by its unique mesh also has good ventilation, wire heat diffusion function in a timely manner.



    Expandable sleeving is braided by environment-friendly polyester monofil

    (PET,PA6,PA66,PPS).

    Working temperature: -50℃~150℃

    Melting point: 250℃±5

    Flame resistant grade:UL VW-1



    2. Characteristics



    1).  Flexibility, fire resistance, abrasive resistance and thermal insulation performance ;

    2).  The sleeving owns smooth surface, bright color, various patterns ;

    3).  Working temperature: -50℃~150℃

    4).  Melting point: 250℃±5

    5).  Flame resistant grade:UL VW-1

    6).  Standard color: Black color



    Feature of pet  expandable braided sleeving





    1.  Strong corrosion resistance,excellent flexibility, easy bending, simplify operation, good scalability, resilience and abrasion resistance.

    2. Application:Products are widely used in computer power cord, audio-video, automotive, aviation, wire and cable industries. It has protect and beautify the role. Its unique mesh characteristics but also has good ventilation, and a thermal diffusion function in a timely manner.

    3. Notes:

    PET expandable sleeving in expanding at the same time can be shorten, about 30%, please reserve enough length.

    Huiyunhai polyester expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    Totally expanded the sleeving can reach at least 1.5 times than the initial dimension.



    Huiyunhai nylon expandable sleeving is made of nylon 6.6 monofilament which offers excellent performance of abrasion resistance. It is lightweight , highly flexible and it can resists to many chemicals agents. Uniquely shaped monofilament provides smooth, soft, slick surface resisting snags when dragged over rough surface.





    Specification for braided sleeves



    Nominal
    Size
    Product
    Part #
    Expansion Range Spool Put-Ups
        Min. Max. Bulk Shop
    1/16"
    1/8"
    1/4"
    3/8"
    1/2"
    5/8"
    3/4"
    1"
    1 1/4"
    1 1/2"
    1 3/4"
    2"
    2 1/2"
    3"
    CBS0.06
    CBS0.13
    CBS0.25
    CBS0.38
    CBS0.50
    CBS0.63
    CBS0.75
    CBS1.00
    CBS1.25
    CBS1.50
    CBS1.75
    CBS2.00
    CBS2.50
    CBS3.00
    3/64"
    3/32"
    1/8"
    3/16"
    1/4"
    3/8"
    1/2"
    5/8"
    3/4"
    1"
    1 1/4"
    1 1/2"
    1 3/4"
    2 1/2"
    3/32"
    1/4"
    7/16"
    1/2"
    3/4"
    1"
    1 1/4"
    1 5/8"
    1 3/4"
    2 1/8"
    2 3/4"
    3 1/2"
    3 5/8"
    4 3/4"
    1,000'
    1,000'
    1,000'
    500'
    500'
    500'
    250'
    250'
    250'
    200'
    200'
    200'
    200'
    100'
    250'
    225'
    200'
    125'
    100'
    100'
    75'
    65'
    50'
    40'
    30'
    50'
    50'
    50'
    3/4" PTL0.75BK 1/2" 1 1/4" 250' 75'
