Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection

Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection

    • Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection
    • Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection
  • Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection

    Product Details:

    Place of Origin: Shenzhen of China
    Brand Name: Huiyunhai
    Certification: UL, RoHS, REACH
    Model Number: HYH

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 meters
    Price: negotiable
    Packaging Details: Standard export carton
    Supply Ability: 500,000 meters per month
    Contact Now
    Detailed Product Description
    Name: Pet Cable Braided Sleeving Color: Red And Black Crossing
    Function: Wire Protection Lead Time: 5 Days
    Feature: Flame Resistant Sample: Free

    Strong Abrasion resistance Pet Braided Sleeving For Industrial Hoses Sleeves Protection





    Premium Cable Management:Crafted with durable & flexible neoprene, not easy to deform, dustproof, waterproof , breathable and washable. Protect multiple cables without tearing while protecting cords from foot traffic & chewing pets.



    Polyester expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors. Totally expanded the sleeving can reach at least 1.5 times the initial dimension.



    Technical data:



    Material: Polyester

    Working temperature: -50℃~+150℃

    Melting point: 240±10℃

    Flammability: VW-1

    Color: Black and grey

    Cutting tool: Hot Knife

    Approval: UL , ROHS, REACH, Halogen Free



    PET Expandable Tube is braided from polyethylene terepthalate (PET) monofilament yarns. The material has a wide operating temperature range, is resistant to chemical degradation, UV radiation, and abrasion. The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.



    Application :



    It is widely used to cover the wires, cables, wire harnesses, pipes and industrial hoses where the additional protection and high flame retardant are required.





    Product feacture:



    The braided sleeve is made of environmentally-friendly PET silk, which has good flexibility, flame retardancy, wear resistance and heat insulation. The product has a smooth surface, bright color and a variety of patterns. Products are widely used in computer power lines, audio and video lines, automotive, aviation, wire and cable industries, to protect and beautify.


    1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
    2. Braided of 0.25mm / 0.2mm Pet monofilament.
    3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    4. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
    5. Logo printing is available.
    6. Customized,Special package is willing to accepted,can be product according to customers requirements.





    Dimensions:



    Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection



    Notes:



    1.  Nominal size indicates the flat width.

    2.  The part No. will be followed with BK, GR and so on to indicate the color of sleeving.

    3.  This sleeving has expandable character, the following sizes are covered by the nearest:16mm=15mm, 19mm =20mm , 32mm =30mm , 38mm=40mm, 51mm=50mm.

    4.  Special packing, sizes, and colors can be supplied upon request.

    5.  All numerical data are average or typical values, not including customized sizes.















    Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection



















    Strong Abrasion Resistance PET Braided Sleeving For Industrial Hoses Protection
