Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses

Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses

  • Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses
  • Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses
Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses
Product Details:
Place of Origin: Shenzhen of China
Brand Name: Huiyunhai
Certification: UL, RoHS, REACH
Model Number: HYH
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard export carton
Supply Ability: 500,000 meters per month
Contact Now
Detailed Product Description
Name: Electrical Braided Sleeving Color: Custom
Function: Wire Protection Logo: Print
Feature: Flame Resistant Sample: Free
High Light:

automotive wire sleeve

,

high temperature braided sleeving

Colorful Polyester PET Braided Expandable Electrical Sleeving To Protect Wire And Cable



Good Sleeves for you:

  •  Form-fitting neoprene stretchy material allows for multiple cables and flexibility each sleeve  can hold up to 8-10 cables
  •  Easy to use, just gather cables together, wrap the sleeve around and zip-up, perfect for   home and office use
  •  Ideal for keeping cords organized behind the TV entertainment system and computer monitor



You don’t need to ruin your cord cover by cutting holes into it. Our cable organizer comes with specially designed cable exits that let you pull out each cable at any desired point. Just gather cables together (holds 8-10 cables) and pull them out of the sleeve at any desired length! This cord hider will look awesome and will make you feel great !



Premium Cable Management:Crafted with durable & flexible neoprene, not easy to deform, dustproof, waterproof , breathable and washable. Protect multiple cables without tearing while protecting cords from foot traffic & chewing pets.



Polyester expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors. Totally expanded the sleeving can reach at least 1.5 times the initial dimension.



Technical data:



Material: Polyester

Working temperature: -50℃~+150℃

Melting point: 240±10℃

Flammability: VW-1

Color: Black and grey

Cutting tool: Hot Knife

Approval: UL , ROHS, REACH, Halogen Free



PET Expandable Tube is braided from polyethylene terepthalate (PET) monofilament yarns. The material has a wide operating temperature range, is resistant to chemical degradation, UV radiation, and abrasion. The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.



Application :



It is widely used to cover the wires, cables, wire harnesses, pipes and industrial hoses where the additional protection and high flame retardant are required.





Product feacture:



The braided sleeve is made of environmentally-friendly PET silk, which has good flexibility, flame retardancy, wear resistance and heat insulation. The product has a smooth surface, bright color and a variety of patterns. Products are widely used in computer power lines, audio and video lines, automotive, aviation, wire and cable industries, to protect and beautify.


1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
2. Braided of 0.25mm / 0.2mm Pet monofilament.
3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
4. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
5. Logo printing is available.
6. Customized,Special package is willing to accepted,can be product according to customers requirements.





Dimensions:



Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses 0



Notes:



1.  Nominal size indicates the flat width.

2.  The part No. will be followed with BK, GR and so on to indicate the color of sleeving.

3.  This sleeving has expandable character, the following sizes are covered by the nearest:16mm=15mm, 19mm =20mm , 32mm =30mm , 38mm=40mm, 51mm=50mm.

4.  Special packing, sizes, and colors can be supplied upon request.

5.  All numerical data are average or typical values, not including customized sizes.





Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses 1















Polyester PET Expandable Braided Sleeving For Protecting Cables / Wire Harnesses 2
