Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves

Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves

    • Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves
    • Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves
  • Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves

    Product Details:

    Place of Origin: Shenzhen of China
    Brand Name: Huiyunhai
    Certification: UL, RoHS, SGS, REACH, ISO
    Model Number: HYH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 meters
    Packaging Details: standard export carton
    Payment Terms: T/T, Western Union
    Supply Ability: 3 million meters per month
    Contact Now
    Detailed Product Description
    Material: PET, Nylon Diameter: 1mm To 100mm
    Color: Black,custom Sample: Free
    Print: Logo, Custom Lead Time: 5 Days

    High Flame Retardant Cable Sleeve For Pet Wire Management Protection





    Technical parameters:

    Applicable Wire OD:custom
    100% brand new and high quality.
    Easy to bend for its excellent softness.
    Expandable, environmentally friendly, non-toxic.
    Good flexibility, elasticity, thermal insulation and abrasion resistance.
    Quick and easy installation over large connectors and long runs is allowed for its unique braided construction and wide expandability.
    Widely used in automotive wiring, cables, optical fiber, audio, wire and other wire protection.





    Main Properties:



    1. Operating temperature: -50°C~150°C



    2. Melting point: 250±5°C.



    3. Flammability: UL VW-1


    4. Standard color: White, Black, Gray, Red, Yellow, Blue,Pink,Orange,Purple,Remix pattern



    5. Cutting tool: Hot knife


    6. Certificate: RoHS, MSDS



    Applications:



    Flame-retardant PET Expandable Braided Sleeving(PETS/PETS-F) is designed from durable environment friendly PET monofilament yarns and the unique braided construction enables quick and easy installation over large connectors. These sleevings are used in wire harnessing in industries, hose and cable protection for the automotive, heavy equipment and marine industries. And generally commercial applications such as personal computers, automotive, motorcycling, bicycling, flyfishing and scuba diving.



    Usage:



    PET Expandable sleeve is widely used in bounding and protecting of electrical cables, automobile and aviation sectors.



    Characteristics:



    •  Operating temperature range: -70~+155ºC
    •  Melt temperature: 250 ºC
    •  Flame retardant, UV resistant, Anti chemicals and solvents, Light weight and Flexible
    •  Standard color: Black, White, Grey, Yellow, Blue, Red, Green etc.

    1. Operating temperature range: -70~+155ºC
    2. Melt temperature: 250 ºC
    3. Flame retardant, UV resistant, Anti chemicals and solvents, Light weight and Flexible
    4. Standard color: Black, White, Grey, Yellow, Blue, Red, Green etc.







    Functions:



    To meet the requirement of wear protection in various industrial fields .it expands the diameter to 1.5 times larger than the original size with unique weaving structure.



    We have one of the most extensive ranges of insulation products, expandable braided sleeving, cable ties, and accessories on the market, suitable for a wide spectrum of industries, from electrical design and construction companies, to manufacturers of electrical products and building industries. Expandable Braided Sleeves is manufactured from Polyethylene Terepthalate, or PET, which has great properties of flexibility and strength, plus a good resistance against chemicals, and when used on wire runs, it adds protection and extra insulation.





    Description:



    High flame retardant braided sleeving is braided by UL 94 VO grade raw material PET mono filaments. It has excellent expandability, abrasive resistance and high flame retardant. Its flame rating can be up to VW-1.
    Application electronics, automobile, high-speed rail,aviation, marine and switch cabinet wire harnessing applications where cost efficiency and durability are critical. The unique braided construction and wide expandability allows quick and easy installation over large connectors and long runs.
    Ease of installation and nearly complete coverage makes fray resistance braided sleeve an ideal solution for many industrial and engineering applications.




    Sizes of the sleeves:







    Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves











    Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves





































    Hot Knife Cutting Flame Retardant Wire Loom , Fire Resistant Cable Sleeves
