High Density PET Expandable Braided Sleeving Black Flexible Cable Protection

High Density PET Expandable Braided Sleeving Black Flexible Cable Protection

  • High Density PET Expandable Braided Sleeving Black Flexible Cable Protection
  • High Density PET Expandable Braided Sleeving Black Flexible Cable Protection
High Density PET Expandable Braided Sleeving Black Flexible Cable Protection
Product Details:
Place of Origin: Shenzhen of China
Brand Name: Huiyunhai
Certification: UL, RoHS, REACH
Model Number: HYH
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard export carton
Supply Ability: 500,000 meters per month
Contact Now
Detailed Product Description
Name: Pet Braided Sleeving Material: Pet,nylon
Size: Custom Fuction: Wear Resistant
Lead Time: 5 Days Usage: Cable Harness
High Light:

expandable wire sleeving

,

braided wire loom



High Density Black PET Expandable Braided Sleeving Flexible Cable Protection


Product feacture:


1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
2. Braided of 0.25mm / 0.2mm Pet monofilament.
3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
4. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
5. Logo printing is available.
6. Customized,Special package is willing to accepted,can be product according to customers requirements.




Structure of pet braided sleeving for model Product NO:643025-8



NO ITEM PARAMETER NO ITEM PARAMETER
A CARRIERS 64 H MATERIAL PET
B STRANDS PER
CARRIERS
3 I COLOR GREY AND BLACK
C STRANDS OD 0.25 J SGS SGS report
D MESH COUNT 8 K EnvironmentalRequirement Product complies with
the EU ROHS standards
E NOMINAL OD ¢20.0MM L management
standard
ISO9001:2016
F MIN. OD ¢20MM M SUPPLIER HUIYUNHAI TECH.CO.,LTD
G MAX. OD ¢40MM N DATE 2018.3.14



Description of pet expandable braided sleeve

Convenient Cable Management: This flexible cable organizer helps secure TV and video game console wires or reduce tangled cords behind your computer desk
Stronger, Heavy-Duty Design: Each wire sleeve is meticulously sewn and reinforced with strong glue and velcro to offer long-lasting stability and use




The selection of this sleeve refers to following four parameters.

A- yarn number (one or three)
B- Diameter of single yarn(0.25mm or 0.20mm)
C- Strand number (48 spindles braiding machine or 72 spindles braiding machine)
D- flat width(1mm or 100mm)

Pet expandable braided sleeve compiled by the Environmental Protection PET filament diameter monofilament 0.20mm or 0.25mm's made with good flexibility, flame resistance, abrasion resistance and heat resistance, network management can be easily expanded to the original 150% , and it is easy to tighten the various irregularly shaped objects, which can be maintained within a wide temperature range while maintaining a soft, can inhibit chemical corrosion, UV and friction, characterized by its unique mesh also has good ventilation, wire heat diffusion function in a timely manner.


Characteristics

1). Flexibility, fire resistance, abrasive resistance and thermal insulation performance ;
2). The sleeving owns smooth surface, bright color, various patterns ;
3). Working temperature: -50℃~150℃
4). Melting point: 250℃±5
5). Flame resistant grade:UL VW-1
6). Standard color: Black color


Application:


1. Automobile wires protection

2. Structured cabling system

3. A/V cables & HDMI cables

4. Industrial hoses & tubes protection

The role of environmentally friendly braided sleeve is as follows:
1 flame retardant: VW-1;
2 water absorption rate: ≤0.5%;
3 Temperature: –50~+150°C;
4 Certification: UL, RoHS, REACH 138 items
5 Material: high quality environmentally friendly PET yarn, polyester yarn, etc.
6 Cutting tools: electric scissors, electric iron, scissors + lighter, professional cutting machine and other tools
7 Features: Excellent softness, easy to bend, loose and tight, easy to wire operation, good stretchability, elasticity and wear resistance.

The environmentally friendly braided sleeve is made of one or more PET, nylon, copper or cotton threads, PP yarn, nylon, and low-elastic yarn. It can be exported to all countries in the world through environmental protection certification.
The environmentally friendly braided sleeve is mainly used in computer power cords, audio video cables, automobiles, aviation, wire and cable industries, etc. It plays a protective and beautifying role and has certain shielding performance. It is most suitable for the audio medical industry, economical and easy to organize. At the same time, it has very good wear and corrosion resistance, suitable for wire harness protection, wear, corrosion, decoration and storage in various mechanical and electronic industries.
The environmentally friendly braided sleeve is made of one or more PET, nylon, copper or cotton threads, PP yarn, nylon, and low-elastic yarn. It can be exported to all countries in the world through environmental protection certification.


Specification for braided sleeves

High Density PET Expandable Braided Sleeving Black Flexible Cable Protection 0





High Density PET Expandable Braided Sleeving Black Flexible Cable Protection 1






























High Density PET Expandable Braided Sleeving Black Flexible Cable Protection 2
