Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection

Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection

    • Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection
    • Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection
  • Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection

    Product Details:

    Place of Origin: Shenzhen of China
    Brand Name: Huiyunhai
    Certification: UL, RoHS, REACH
    Model Number: HYH

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 meters
    Price: negotiable
    Packaging Details: Standard export carton
    Supply Ability: 500,000 meters per month
    Contact Now
    Detailed Product Description
    Name: Pet Braided Sleeving Material: Pet,nylon
    Size: Custom Fuction: Wear Resistant
    Lead Time: 5 Days Usage: Cable Harness



    Red PET Expandable Braided Sleeving For Wire / Hose / Cable Harness Protection


    Product feacture:


    1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
    2. Braided of 0.25mm / 0.2mm Pet monofilament.
    3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    4. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
    5. Logo printing is available.
    6. Customized,Special package is willing to accepted,can be product according to customers requirements.




    Structure of pet braided sleeving


    Expandable sleeving is braided with environment-friendly polyester monofil. (PET, PA6, PA66, PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.

    Our PET braided sleeving has excellent wear resistance,elasticity,smoothness,flame retardancy and is made of industrial,high strength,environmentally friendly non-toxic 1.0 viscosity PET mono or multifilament.We can make sleevings of different widths, colors and patterns with mono or multifilament according to customer's request.Widely used for various types of automotive and aircraft wiring,consumer electronics, computers and other wire industry.


    The selection of this sleeve refers to following four parameters.

    A- yarn number (one or three)
    B- Diameter of single yarn(0.25mm or 0.20mm)
    C- Strand number (48 spindles braiding machine or 72 spindles braiding machine)
    D- flat width(1mm or 100mm)

    Pet expandable braided sleeve compiled by the Environmental Protection PET filament diameter monofilament 0.20mm or 0.25mm's made with good flexibility, flame resistance, abrasion resistance and heat resistance, network management can be easily expanded to the original 150% , and it is easy to tighten the various irregularly shaped objects, which can be maintained within a wide temperature range while maintaining a soft, can inhibit chemical corrosion, UV and friction, characterized by its unique mesh also has good ventilation, wire heat diffusion function in a timely manner.


    Characteristics

    1). Flexibility, fire resistance, abrasive resistance and thermal insulation performance ;
    2). The sleeving owns smooth surface, bright color, various patterns ;
    3). Working temperature: -50℃~150℃
    4). Melting point: 250℃±5
    5). Flame resistant grade:UL VW-1
    6). Standard color: Black color

    Notes:

    PET expandable sleeving in expanding at the same time can be shorten, about 30%, please reserve enough length.
    Huiyunhai polyester expandable sleeving is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
    Totally expanded the sleeving can reach at least 1.5 times than the initial dimension.



    Application:



    Products are widely used in computer power cord, audio-video, automotive, aviation, wire and cable industries. It has protect and beautify the role. Its unique mesh characteristics but also has good ventilation, and a thermal diffusion function in a timely manner.


    1. Automobile wires protection

    2. Structured cabling system

    3. A/V cables & HDMI cables

    4. Industrial hoses & tubes protection

    The role of environmentally friendly braided sleeve is as follows:
    1 flame retardant: VW-1;
    2 water absorption rate: ≤0.5%;
    3 Temperature: –50~+150°C;
    4 Certification: UL, RoHS, REACH 138 items
    5 Material: high quality environmentally friendly PET yarn, polyester yarn, etc.
    6 Cutting tools: electric scissors, electric iron, scissors + lighter, professional cutting machine and other tools
    7 Features: Excellent softness, easy to bend, loose and tight, easy to wire operation, good stretchability, elasticity and wear resistance.


    Specification for braided sleeves

    Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection















    Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection




































    Red Color High Temp Braided Sleeving For Wire / Hose / Cable Harness Protection
