Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve

Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve

Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve
Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve
Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve
Product Details:
Place of Origin: China
Brand Name: HYH Tech
Certification: RoHS, REACH, SGS, ISO
Model Number: HYH-080
Payment & Shipping Terms:
Minimum Order Quantity: 1000m
Price: Negotiable
Packaging Details: reel with carton
Delivery Time: 10 working days
Payment Terms: L/C, T/T
Supply Ability: 1000000 m per month
Contact Now
Detailed Product Description
Material: Coated Silicone Resin And Fiberglass Braided Color: White
Size: 3mm - 32mm Type: Insulation Tube
Operating Range: -60°C-600°C Certification: RoHS, REACH, SGS, ISO
High Light:

Alkali Free Heat Resistant Wire Sleeve

,

0.18mm Heat Resistant Wire Sleeve

,

0.18mm High Temperature Fiberglass Sleeve

Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve



Fiberglass Sleeve Coated Silicone Resin Good Flexibility And Mechanical Properties Resistance To Acid And Oil





Description:



  • [PARAMETER] Material: Alkali-free Fiberglass; Length: 5 Meter / 16.4 Feet; Inner Diameter: 3mm; Thickness: 0.18mm; Working Temp Range: –60℃~+600℃; Working Voltage: 500V~800V; Flame Resistance: VW-1.
  • [FEATURE] This heat sleeve fiberglass are for high temperature applications, also, it keeps wire neat and organized.
  • [MADE] This product is made of alkali-free fiberglass. Then coated with a small amount of binder. Lastly, process the pipe under a high temperature.
  • [APPLICATION] The heat shield tubing is mainly applied to insulate and heat equipment, such as motor, engine, plug wire, fuel lines, decorative light, etc.
  • [NOTE] Electrical wires should never be hot. Should increase the gauge of wire if you are exceeding the recommended load of that wire. This product would make the wire get hot by not letting it cool and might melt the insulation on said wire.



Technical data:

Operating range: -60°C-600°C

Breakdown voltage: 700V

Flammability: Self-extinguish

Color: White

Cutting tool: Scissors

Approval: RoHS



Specification
item
value
Working temperature
-60 C~ 600 C
Rated voltage
1.2KV / 1.5V / 2.5KV / 4KV / 7KV / 10KV
Uses
This product is widely used in commercial electronics, household appliances insulation, electronic transformers, automotive wiring
harness, energy-saving lamps, electronic equipment, equipment, internal cable protection and insulation treatment.
Color
white
Type
Insulation tube





Datasheet:



Part No. I.D.(I) Wall thickness(t) Packing (L)
HYH-FG-003 3 0.2 100 m/roll
HYH-FG-004 4 0.3 100 m/roll
HYH-FG-005 5 0.3 100 m/roll
HYH-FG-006 6 0.3 100 m/roll
HYH-FG-007 7 0.35 100 m/roll
HYH-FG-008 8 0.35 50 m/roll
HYH-FG-010 10 0.35 50 m/roll
HYH-FG-012 12 0.35 50 m/roll
HYH-FG-015 15 0.43 50 m/roll
HYH-FG-018 18 0.43 50 m/roll
HYH-FG-020 20 0.43 50 m/roll





Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve 0



Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve 1



Alkali Free Heat Resistant Wire Sleeve High Temperature Fiberglass Sleeve 2



FAQ:





Q1. What is your terms of packing?
A: Usually, we pack the sleeves on a spool with 100-500 meter as your request. Then we put the spools into master cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 100% in advance. if your order is big, the payment term could be negotiable.

Q3. What is your terms of delivery?
A: FOB, CFR, CIF, DDP.



Q4. What is your price term?

A: FOB Shenzhen for order value over USD5,000, if less than USD5,000 the term is EX Works.

Q5. How about your delivery time?
A: Generally, it will take 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Urgent orders can provide overtime production.

Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q7. What is your sample policy?
A:
We can provide free samples, the customers need to pay the courier cost.

Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test and FQC before delivery.

Q9: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure your benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
