Brand Name: | Huiyunhai |
Model Number: | HYH |
MOQ: | Negotiable |
Price: | Negotiable |
Packaging Details: | Standard export carton |
Payment Terms: | T/T, Western Union |
40mm Flame Retardant PET Braided Sleeving / Expandable Braided Sleeve With PET
Description of braided sleeves:
Our PET braided sleeving is divided into non woven flame retardant, flame retardant and high flame retardant.PET general braid commonly used in the subway, railway, automobile, aviation, switch cabinet, computer power line, optical fiber line, HDMI line and other industries, to organize, to protect and beautify the earth line, the function of anti friction.
Color: can be customized as needed
Size : 1MM--100MM
Parameters : single silk, double silk, three or more silk braided wire.
Our features :
1 . The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
2 . Totally expanded the sleeving can reach at least one point five times than the initial dimension.
3 . Suitable for constructing and protecting cable harnesses or tidying cable looms.
4 . Sleeve expands to allow the cables to pass through and then automatically shrinks back.
5 . Multiple sizes and lengths available
Excellent softness, easy to bend.
Durable in use.
Can be used for wire and cable protection, pipe and hose, indoor wiring etc.
Our normal sizes available:
Nominal Size |
Product Part # |
Expansion Range | Spool Put-Ups | ||
Min. | Max. | Bulk | Shop | ||
1/16" 1/8" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1 1/4" 1 1/2" 1 3/4" 2" 2 1/2" 3" |
CBS0.06 CBS0.13 CBS0.25 CBS0.38 CBS0.50 CBS0.63 CBS0.75 CBS1.00 CBS1.25 CBS1.50 CBS1.75 CBS2.00 CBS2.50 CBS3.00 |
3/64" 3/32" 1/8" 3/16" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1 1/4" 1 1/2" 1 3/4" 2 1/2" |
3/32" 1/4" 7/16" 1/2" 3/4" 1" 1 1/4" 1 5/8" 1 3/4" 2 1/8" 2 3/4" 3 1/2" 3 5/8" 4 3/4" |
1,000' 1,000' 1,000' 500' 500' 500' 250' 250' 250' 200' 200' 200' 200' 100' |
250' 225' 200' 125' 100' 100' 75' 65' 50' 40' 30' 50' 50' 50' |
3/4" | PTL0.75BK | 1/2" | 1 1/4" | 250' | 75' |
