Braided Sleeving, Colorful Life
 |
| Place of Origin: | Shenzhen of China |
| Brand Name: | Huiyunhai |
| Certification: | UL, RoHS, REACH, SGS, ISO |
| Model Number: | HYH-HC |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | standard export carton |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 3 million meters per month |
| Product Name: | Expandable Sleeving | Width: | Optional, Custom |
|---|---|---|---|
| Usage: | Automobile And Aviation Sectors. | Color: | Optional, Custom |
| Function: | Automobile Wires Protection | Standard: | UL, CSA, ROHS, REACH |
| High Light: | flexible braided wire covering,high temperature wire sleeve |
||
Fire Retardant Flexible Braided Wire Covers For Expandable Sleeving Cable Organizer
PET Expandable Braided Sleeving is designed from durable environment friendly PET monofilament yarns and the unique braided construction enables quick and easy installation over large connectors. These sleevings are used in wire harnessing in industries, hose and cable protection for the automotive, heavy equipment and marine industries. And generally commercial applications such as personal computers, automotive, motorcycling, bicycling, flyfishing and scuba diving.
Product description of braided sleeves
Flame Resistant Thermal Wire Insulation PET Braided Sleeve is braided with environment-friendly polyester monofil. (PET, PA6, PA66, PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.
1. Operating temperature range: -70~+155ºC
2. Melt temperature: 250 ºC
3. Flame retardant, UV resistant, Anti chemicals and solvents, Light weight and Flexible
4. Standard color: Black, White, Grey, Yellow, Blue, Red, Green etc.
Features of braided sleeves
> Flame-retardant
> Easy, Cost & Labor Effective Installation
> More Flexible Than Split Convoluted or Spiral Wrap
> Cuts easily with hot knife or scissor
> Cut & abrasion resistant
> 25% Edge Overlap
> Chemical inert
> ROHS compliant
> UV resistant
> Cost effective wrap around solution
> Retains shape & rigidity throughout operating temperature range (-40°C to 125°C)
> Melt Temp 230°C
Technical Data:
| Mono filament Thickness | 0.25mm or 0.20mm |
| Recommended Cutting | Hot Knife |
| Tensile Strength | 100,000psi |
| Elongation | 20% |
| Max Temperature | 155C |
| Melt Temperature | 250C |
| Copper rust |
No Effect |
