| Brand Name: | Huiyunhai |
| Model Number: | HYH-Auto |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | standard export carton |
| Payment Terms: | T/T, Western Union |
Wear Resistant Flexible Automotive Braided Sleeving For Cable Wire Harness
Advantages of automotive cable sleeving:
a. Offering durable abrasion resistance in a wide range of industrial applications.
b. Offering kink resistance with good strength and flexibility.
c. Totally expanded the sleeving can reach at least one point five times than the initial dimension.
Application of braided sleeves
1. Automobile wires protection
2. Structured cabling system
3.A/V cables & HDMI cables
4.Industrial hoses & tubes protection
PET Expandable Sleeving used to Cover Cables for Protecting the Cables are selling all over the world now!!!
a. Protecting cover cables, wire harnesses, tubes etc.
b. used in bounding and protecting of electrical cables, automobile and aviation sectors.
1. Description of goods
Expandable sleeving is braided by environment-friendly polyester monofil
(PET,PA6,PA66,PPS).
Working temperature: -50℃~150℃
Melting point: 250℃±5
Flame resistant grade:UL VW-1
2. Characteristics
1). Flexibility, fire resistance, abrasive resistance and thermal insulation performance ;
2). The sleeving owns smooth surface, bright color, various patterns ;
3). Working temperature: -50℃~150℃
4). Melting point: 250℃±5
5). Flame resistant grade:UL VW-1
6). Standard color: Black color
3. Range of application
Expandable sleeving is widely used in bounding and protecting of electrical cables, automobile and aviation sectors.
4. Feature:
Material: Polyester surface
Color: Black,Red,Blue,Pink,Yellow,Green, etc
Feature: Excellent flexibility, Easy bending, Simplify operation, Good scalability, Resilience and Abrasion resistance. PET expandable braided sleeving
Fire rating: VW-1
Nominal temperature: -55 °C~+155 °C
Melting point: 230°C±5°C
Product certification: UL,RoHS
1. This kind of braided sleeving consist of tough and strong Nyon 66 flat filaments which exceeds the durability of other plastic sleevings in abrasion comparison without losing the attractive look and flexibility.
2. Uniquely shaped monofilament provides soft and smooth surface to resist snags when dragged over rough object.
Cable Sleeving Solutions
Cable sleeving is one of the best looking and most diverse wire management solutions available. Whether you're looking for wire loom, conduit, braided sleeving or spiral wrap, we've got the sleeving solution for your application.
Wire loom and conduit offer full-coverage protection for cables and wires, protecting from abrasion, moisture and the elements.
The unique properties of PET Expandable Braided Sleeving enable quick and easy installation over irregularly shaped areas, including large connectors. PET expandable sleeving is readily used for cable management in the automotive, computer, industrial, scuba, electronics, A/V industries, and the military. This sleeving also works great around the home and office, for PC cable management or TV cables in your home theater.
1) Extreme abrasion resistance
2) Resistants common chemicals
3) Heavy duty and flexible
4) Superior flame, cut, and abrasion resistance
5) Super strength and abrasion resistance
The open weave design provides flexibility for dynamic applications, while the increased braid density offers added protection. Fray resistance braided expandable sleeving is the ideal products to protect your cables.
Sizes of pet braided sleeves:
| Model | Natural OD(MM) |
Max Expand OD(MM) |
N.W(g) | Packing (M/spool) |
Model | Natural OD(MM)) |
Max Expand OD(MM) |
N.W(g) | Packing (M/spool) |
|
| 161020 | 1 | 2 | 2.5 | 1000 | 641025 | 8 | 16 | 7 | 500 | |
| 161025 | 1 | 2 | 2.5 | 1000 | 642020 | 12 | 25 | 10.5 | 500 | |
| 162020 | 2 | 4 | 3 | 1000 | 642025 | 14 | 30 | 12 | 500 | |
| 162025 | 3 | 6 | 3 | 1000 | 643020 | 16 | 32 | 14 | 500 | |
| 163020 | 3 | 6 | 4 | 1000 | 643025 | 18 | 35 | 17 | 250 | |
| 163025 | 4 | 8 | 4 | 1000 | 721020 | 8 | 16 | 6.5 | 800 | |
| 241020 | 2 | 4 | 3 | 1000 | 721025 | 9 | 18 | 7.5 | 800 | |
| 241025 | 2 | 4 | 3 | 1000 | 722020 | 14 | 28 | 12 | 500 | |
| 242020 | 3 | 6 | 4.5 | 1000 | 722025 | 16 | 32 | 14 | 500 | |
| 242025 | 4 | 8 | 4.5 | 1000 | 723020 | 18 | 35 | 16 | 300 | |
| 243020 | 4 | 8 | 5 | 800 | 723025 | 23 | 45 | 19 | 200 | |
| 243025 | 5 | 10 | 5.5 | 500 | 961020 | 10 | 20 | 8 | 500 | |
| 321020 | 3 | 6 | 3 | 1000 | 961025 | 11 | 22 | 9 | 560 | |
| 321025 | 3 | 6 | 3 | 1000 | 962020 | 20 | 40 | 14 | 500 | |
| 322020 | 5 | 10 | 4.5 | 500 | 962025 | 25 | 50 | 16 | 500 | |
| 322025 | 6 | 12 | 4.5 | 500 | 963020 | 28 | 55 | 18 | 300 | |
| 323020 | 6 | 12 | 6 | 500 | 963025 | 35 | 70 | 25 | 100 | |
| 323025 | 7 | 14 | 7.5 | 500 | 964020 | 30 | 60 | 26 | 100 | |
| 401020 | 4 | 8 | 3.5 | 800 | 964025 | 36 | 72 | 28 | 100 | |
| 401025 | 4 | 8 | 3.5 | 800 | 965025 | 40 | 80 | 46 | 100 | |
| 402020 | 6 | 12 | 5.5 | 500 | 1201020 | 10 | 20 | 10 | 300 | |
| 402025 | 8 | 14 | 6 | 500 | 1201025 | 12 | 22 | 13 | 300 | |
| 403020 | 8 | 16 | 7 | 600 | 1202020 | 22 | 45 | 15 | 200 | |
| 403025 | 10 | 20 | 10 | 400 | 1202025 | 26 | 32 | 18 | 100 | |
| 481020 | 5 | 10 | 4 | 1000 | 1203020 | 32 | 65 | 26 | 100 | |
| 481025 | 6 | 12 | 4.5 | 500 | 1203025 | 38 | 75 | 32 | 100 | |
| 482020 | 8 | 16 | 5.5 | 500 | 1204020 | 40 | 80 | 30 | 100 | |
| 482025 | 10 | 20 | 7.5 | 500 | 1204025 | 45 | 90 | 40 | 100 | |
| 483020 | 10 | 20 | 8.5 | 600 | 1205025 | 50 | 100 | 50g | 50 | |
| 483025 | 12 | 25 | 12 | 300 | 1206025 | 64 | 130 | 60g | 50 | |
| 561020 | 6 | 12 | 5 | 1000 | 1207025 | 76 | 150 | 70g | 50 | |
| 561025 | 7 | 14 | 6 | 800 | 1486025 | 80 | 160 | 80g | 50 | |
| 562020 | 10 | 20 | 8.5 | 500 | 1487025 | 90 | 180 | 90g | 50 | |
| 562025 | 12 | 25 | 10 | 500 | 1488025 | 100 | 200 | 100g | 50 | |
| 563020 | 14 | 30 | 11 | 500 | flat1053020 | |||||
| 563025 | 16 | 32 | 15 | 250 | flat1053025 | |||||
| 641020 | 7 | 14 | 6 | 1000 | flat1054025 |
|
|
