Brand Name: | Huiyunhai |
Model Number: | HYH |
MOQ: | Negotiable |
Price: | Negotiable |
Packaging Details: | Standard export carton |
Payment Terms: | T/T, Western Union |
Durable PET Expandable Braided Sleeve Cable For Wire Harness
Description for Durable PET Expandable Braided Sleeve
Expandable braided sleeves is ideal for a limitless number of electronic, automotive, marine and industrial wire management and bundling applications. Examples include engine compartment dress up, home theater wire management, customizing computer case wiring, office wire management, automotive harnesses, scuba hose protection, and many more. Threads of different colors and textures could be braided into different patterns. Each of our products is tailored to the client's business and needs.
With excellent flexibility, flame resistance, wear resistance and heat insulation.
Strong corrosion resistance and abrasion resistance.
Excellent softness, easy to bend.
Durable in use.
Can be used for wire and cable protection, pipe and hose, indoor wiring etc.
Cable sleeve offers durable abrasion resistance in a wide range of industrial applications.
The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
Totally expanded the sleeving can reach at least one point five times than the initial dimension.
Technical data of Durable PET Expandable Braided Sleeve
1. Size: 3~ 100 mm
2. Operating range: -103F to 257F (-75C to 125C) temperature range
3. Melt Point:446F (230C)
4. Expands up to 150%
5. Available up to 4" in diameter
6. Colors:black, grey, white, red, green, blue, yellow, purple, pink, orange etc.
7. Certificate: SGS, UL, RoHS approved
8. Halogen free
Dimension Data of Durable PET Expandable Braided Sleeve
Nominal Size |
Product Part # |
Expansion Range | Spool Put-Ups | ||
Min. | Max. | Bulk | Shop | ||
1/16" 1/8" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1 1/4" 1 1/2" 1 3/4" 2" 2 1/2" 3" |
CBS0.06 CBS0.13 CBS0.25 CBS0.38 CBS0.50 CBS0.63 CBS0.75 CBS1.00 CBS1.25 CBS1.50 CBS1.75 CBS2.00 CBS2.50 CBS3.00 |
3/64" 3/32" 1/8" 3/16" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1 1/4" 1 1/2" 1 3/4" 2 1/2" |
3/32" 1/4" 7/16" 1/2" 3/4" 1" 1 1/4" 1 5/8" 1 3/4" 2 1/8" 2 3/4" 3 1/2" 3 5/8" 4 3/4" |
1,000' 1,000' 1,000' 500' 500' 500' 250' 250' 250' 200' 200' 200' 200' 100' |
250' 225' 200' 125' 100' 100' 75' 65' 50' 40' 30' 50' 50' 50' |
3/4" | PTL0.75BK | 1/2" | 1 1/4" | 250' | 75' |
Detailed Description of Durable PET Expandable Braided Sleeve
Model Number | PET Expandable Braided Sleeving |
Certification | UL ROHS |
Place of Origin | Shenzhen of China |
MOQ | 1000 meters |
Price | Deliberate |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 50000meters /day |
Delivery Time | 5-7days |
Packaging Details | Roll |
Material | PET |
Melting Point | 230C+5 |
Temperature Range | -50C ~+150C |
Fire Resistance Rating | VW-1 |
Certificate | SGS, Reach And ROHS |
Colors | Black/white/clrear/blue/pink/yellow/red/yellow |
