Self Wrapping Split Braided Sleeving
>
Expandable Self Wrapping Split Braided Sleeving PET Self Closing Braided Wire Wrap

Expandable Self Wrapping Split Braided Sleeving PET Self Closing Braided Wire Wrap

Brand Name: HYH TECH
Model Number: HYH-301
MOQ: Negotiable
Price: Negotiable
Packaging Details: 100 - 500 meters/spool
Payment Terms: T/T
Detail Information
Place of Origin:
Shenzhen of China
Certification:
UL, RoHS, REACH, SGS, ISO
Material:
PET, PP
Size:
6mm-50mm
Color:
Customized
Cutting Tool:
Hot Cutting Knife
Feature:
Expandable, Flame Retardant, Cable And Wire Harnesses Protection
Certificates:
UL, RoHS, REACH, SGS, ISO
Supply Ability:
3 million meters per month
High Light:

Expandable Self Wrapping Split Braided Sleeving

,

PET Self Wrapping Split Braided Sleeving

,

PET Self Closing Braided Wire Wrap

Product Description

Expandable Self Wrapping Split Braided Sleeving PET Self Closing Braided Wire Wrap



What's the special of PET Self Closing Wrap Braided Expandable Sleeving For Cable Harness


1. Flame-retardant and halogen-free.

2. It offers durable abrasion resistance in a wide range of industrial applications.

3. The open weave construction allows an easy installation on a bundle of hoses
and cables, even if some with bulky or large connectors.



Self-Closing Braided Sleeving is made of PET monofilament and PET multifilament or PET monofilament and Nylon multifilament,and then it is naturally rolled into a roll by a special process.The winding coverage can reach 25%.Easy to install and remove,beautiful,flame retardant,anti-wear.Mainly used for wiring of automobiles,military,ship, communication cable.





Application of PET Self Closing Wrap Braided Expandable Sleeving For Cable Harness



Its ideal for application in wire harness, automatic equipment, railways, general manufacturing industry where wires and tubes need a tough and durable protection.



Dose not trap heat or humidity Rot-free , Self-fitting over many shapes and sizes Self-extinguishing when used to encase typical non-flammable wires or cable Fray resistant.



Technical data of PET Self Closing Wrap Braided Expandable Sleeving For Cable Harness


1. Material: Polyester

2. Operating range: - 50ºC - +150ºC

3. Melt Point: 250ºC+-5ºC

4. Flammability: VW-1





Self closing sleeve is a non-expandable sleeve woven from monofilament weft and multi-filament warp. provides a lightweight, cost effective and tough solution for protection of a wide range of wire and cable. Its inherent flexibility allows it to be bend, coil and fit with irregular shapes while its open design allows it to be install on finished assemblies quickly.





Description of PET Self Closing Wrap Braided Expandable Sleeving For Cable Harness



PET Self Closing Wrap Braided Cable Sleeve has been engineered from the ground up to meet the demanding specifications of today's modern wiring harness industry.

The new woven construction provides superior elastic flexibility with unbeatable coverage over any harness assembly. Wire harness professionals will also appreciate the increased abrasion resistance PET Self Closing Wrap Braided Cable Sleeve will provide to their cable assemblies.





Our data description of PET Self Closing Wrap Braided Expandable Sleeving For Cable Harness





Part No.

I.D

(d)

Overlap

(%)

Max. Bundle Dia. Packing
(L)
HYH-006 6.0 mm 25 7.0 mm 100m
HYH-009 9.0 mm   10.0 mm 100m
HYH-013 13.0 mm   14.0 mm 50m
HYH-016 16.0 mm   17.0mm 25m
HYH-019 19.0 mm   20.0 mm 25m
HYH-025 25.0 mm   26.0 mm 25m
HYH-032 32.0 mm   33.0 mm 25m
HYH-038 38.0 mm   40.0 mm 25m
HYH-050 50.0 mm   52.0 mm 25m





















Expandable Self Wrapping Split Braided Sleeving PET Self Closing Braided Wire Wrap 0













Expandable Self Wrapping Split Braided Sleeving PET Self Closing Braided Wire Wrap 1





FAQ:





Q1. What is your terms of packing?
A: Usually, we pack the sleeves on a spool with 100-500 meter as your request. Then we put the spools into master cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 100% in advance. Different payment terms against countries.

Q3. What is your terms of delivery?
A: FOB, CFR, CIF, DDU.



Q4. What is your price term?

A: FOB Shenzhen for order value over USD5,000, if less than USD5,000 the term is EX Works.

Q5. How about your delivery time?
A: Generally, it will take 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Urgent orders can provide overtime production.

Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q7. What is your sample policy?
A:
We can provide free samples, the customers just need to pay the courier cost.

Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test and FQC before delivery.

Q9: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure your benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
