Heat Resistant Wire Sleeve
>
PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color

PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color

Brand Name: HYH
Model Number: HYH-0293
MOQ: Negotiable
Price: Negotiable
Packaging Details: 100m/spool, with standard export carton
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
UL, RoHS, SGS, REACH, ISO, IATF16949
Features:
High Temperature Resistant
Material:
PEEK Monofilament
Size:
1-100mm
Color:
Black, Yellow
Application:
Aerospace, Automotive, Teletronic And Chemical Process Industries
LOGO:
Customized
Packing:
100m/spool Within Carton
Cutting Tool:
Hot Knife Cutting, Scissors
Supply Ability:
5 million meters per month
High Light:

PEEK Monofilament Expandable Braided Sleeving

,

100m/spool Expandable Braided Sleeving

,

Golden Expandable Braided Cable Sleeve

Product Description

High Temperature Resistant Golden Color PEEK Expandable Braided Sleeving



PEEK braided sleeve (PolyEtherEther-Ketone) is a high performance advanced poly- mer with outstanding physical properties. PEEK braided sleeve is inherently flame retardant, with a V-0 flammability rating, will withstand continuous use in superheated water or steam up to 500°F, and resists most acids, solvents, and bases.

This material is environmentally friendly and non-toxic, which can resists damage from radiation, and will continue to perform in UHV (Ultra High Vacuum) environments. PEEK braided sleeve is extensively used in the aerospace, automotive, teletronic, and chemical process industries, and is considered an advanced biomaterial used in medical implants and other biomedical applications. PEEK braided sleeve will withstand thousands of sterilization cycles without damage or degradation.

PEEK braided expandable sleeving is tightly braided from 10 mil filaments of pure, unfilled PEEK polymer. The sleeving expands to fit over connectors and splices, and provides full coverage over wires hoses and cable bundles in advanced engineering applications.



Technical data:

Material: PolyEtherEther-Ketone

Operating range: -70°C - +260°C

Melt point: 334±10°C

Flammability: UL VW-0

Standard colors: Black, Yellow

Certificate: UL, RoHS, REACH, Halogen Free

Cutting tool: hot knife cutting or scissors







PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color 0





PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color 1









PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color 2





PEEK Monofilament Expandable Braided Sleeving High Temperature Resistant Golden Color 3





Product Parameter:



Product Sizes

Size Part Number Expansion Max Expansion Min Bulk Spool Shop Spool Lbs / 100'
1/8" HYH-BS-3 1/4" 3/32" 1,000' 225' 0.2
1/4" HYH-BS-6 7/16" 1/8" 1,000' 200' 0.3
3/8" HYH-BS-10 1/2" 3/16" 500' 125' 0.57
1/2" HYH-BS-12 3/4" 1/4" 500' 100' 0.77
5/8" HYH-BS-16 1" 3/8" 500' 100' 0.95
3/4" HYH-BS-24 1 1/4" 1/2" 250' 75' 1.2
1" HYH-BS-19 1 5/8" 5/8" 250' 65' 1.34

1,Other specifications sizes can also be customized.

2,Because the PEEK sleeving has extendable.Therefore, there is a tolerance range of 1mm-2mm.
The larger the size, the larger tolerance.

3,Please inquire for details according to each specification.





FAQ:





Q1. What is your terms of packing?
A: Usually, we pack the sleeves on a spool with 100-500 meter as your request. Then we put the spools into master cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 100% in advance. Different payment terms against countries.

Q3. What is your terms of delivery?
A: FOB, CFR, CIF, DDU.



Q4. What is your price term?

A: FOB Shenzhen for order value over USD5,000, if less than USD5,000 the term is EX Works.

Q5. How about your delivery time?
A: Generally, it will take 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. Urgent orders can provide overtime production.

Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q7. What is your sample policy?
A:
We can provide free samples, the customers just need to pay the courier cost.

Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test and FQC before delivery.

Q9: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure your benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
