Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment

Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment

Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment
Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment
Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment
Product Details:
Place of Origin: Shenzhen of China
Brand Name: Huiyunhai
Certification: UL, RoHS, REACH
Model Number: HYH
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Standard export carton
Supply Ability: 500,000 meters per month
Contact Now
Detailed Product Description
Name: Expandable Braided Sleeving Function: Cable Protection
Feature 1: Wear Resistant Feature 2: Resists Chemicals
Material: Pet Feature 3: Light Weight
High Light:

Electrical Expandable Braided Sleeving

,

Cable Protection Expandable Braided Sleeving

,

RoHS pet braided cable sleeve

Cable Protection Electrical Expandable Braided Sleeving For Auto Equipment



Main Advantages of PET Electrical Braided Sleeving
1. Light weight & Flexible & Insulation & UV Resistant & Decoration & Flame-retardant & Durable abrasion resistance & Resistant to chemical degradation, in a wide range of industrial applications.
2. Braided of 0.25mm / 0.2mm / 0.12 silk monofilament.
3. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.
4. Totally expanded the sleeving can reach twice than the initial dimension.
5. Logo printing is available.
6. Customized,Special package is willing to accepted,can be product according to customers requirements.


Application of Electrical Braided Sleeving
It's used to cover cables, wire harnesses, tubes, industrial hoses, Automotive, Automatic equipment, where is required an additional protection.
1. Automobile wires protection
2. Structured cabling system
3. A/V cables & HDMI cables
4. Industrial hoses & tubes protection


product description of Electrical Braided Sleeving

PET cable sleeving, braided expandable sleeve is braided by environment-friendly polyester monofil. (PET(polyester) cable sleeve possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns. The open weave constrcture allows an easy installation on a bundle of hoses and cables,even if some with bulky or large connectors.

Multi-purpose metal braid provides shielding and grounding for equipment or wire harnesses , to protect your investment
Aesthetically pleasing design is commonly used to decorate or conceal hoses and wires in automotive applications
Expandable design allows for quick and easy installation of cable or wire bundles
Quality tinned copper braid can be easily soldered to connectors and used for custom-length earth straps

Resists chemicals and the elements for use in rugged or exposed applications
Durable construction provides superior protection from accidental cuts or consistent abrasion





Dimensions of cable sleeving:


Width Expandable range Packing
(m/roll)
Inch mm Min. Max.
1/8 3 1 6 500
1/4 6 3 9 500
5/16 8 5 16 400
3/8 10 7 19 400
1/2 12 8 24 300
5/8 15 10 27 300
3/4 20 14 30 250
1 25 18 35 200
1 1/4 30 20 50 150
1 1/2 40 30 60 100
1 3/4 45 35 75 100
2 50 40 80 100
2 1/2 64 45 105 100
3 76 64 120 100


Notes:


1. Nominal size indicates the flat width.

2. The part No. will be followed with BK, GR and so on to indicate the color of sleeving.

3. This sleeving has expandable character, the following sizes are covered by the nearest:16mm=15mm, 19mm =20mm , 32mm =30mm , 38mm=40mm, 51mm=50mm.

4. Special packing, sizes, and colors can be supplied upon request.

5. All numerical data are average or typical values, not including customized sizes.
