Braided Sleeving, Colorful Life
 |
| Place of Origin: | Guangdong, China |
| Brand Name: | HuiYunHai |
| Model Number: | 201 |
| Minimum Order Quantity: | 1000 meters |
|---|---|
| Price: | $0.22 - $4.50/meters |
| Packaging Details: | Spool + carton |
| Supply Ability: | 9999999 Piece/Pieces per Month |
| Type: | Self Closing Cable Sleeve | Material: | PET And PP |
|---|---|---|---|
| Working Temperatur: | -50°C----150°C | Melting Point: | 250℃ |
| Flammability: | UL94 V2 | Certified: | RoHS,Halogen Free |
| Standard Colors: | Black,white,grey,yellow And So On | Cutting Tool: | Hot Knife |
| Application: | The Products Are Widely Used In High-speed Railway | Port: | Shenzhen |
| High Light: | Self Closing Split Wrap Braided Sleeve,PET Split Braided Cable Sleeve,RoHS Certified Split Braided Wire Sleeve |
||
|
Technique Data-Sheet
|
|
|
|
Material:
|
PET and PP
|
|
|
Working Temperature:
|
-50°C----150°C
|
|
|
Melting Point:
|
250℃
|
|
|
Flammability:
|
UL94 V2
|
|
|
Certified:
|
RoHS,Halogen Free
|
|
|
Standard Colors:
|
Black,white,grey,yellow and so on.
|
|
|
Cutting Tool:
|
Hot Knife
|
|
|
Application:
|
The products are widely used in high-speed railway, automobile, automation equipment and computer wire, especially in the
environment that needs protection and heat dissipation. |
|
|
Size specification
|
|
|
|
|
||||
|
Model No.
|
Inner d%iameter(d)
|
Coincidence rate(%)
|
Max wire harness diameter
|
Packing(L)
|
||||
|
SCW-006
|
6.0
|
25
|
7.0
|
100m/Roll
|
||||
|
SCW-009
|
9.0
|
|
10.0
|
100m/Roll
|
||||
|
SCW-013
|
13.0
|
|
14.0
|
50m/Roll
|
||||
|
SCW-016
|
16.0
|
|
17.0
|
50m/Roll
|
||||
|
SCW-019
|
19.0
|
|
20.0
|
25m/Roll
|
||||
|
SCW-025
|
25.0
|
|
26.0
|
25m/Roll
|
||||
|
SCW-032
|
32.0
|
|
33.0
|
25m/Roll
|
||||
|
SCW-038
|
38.0
|
|
40.0
|
25m/Roll
|
||||
|
SCW-050
|
50.0
|
|
52.0
|
25m/Roll
|
||||
